Description +
Details
- General Purpose Thin Wall Tubing is designed to insulate, colour code, strain relieve and provide abrasion and mechanical protection
- Manufactured from a 2:1 heat shrink ratio, flexible, flame retardant, irradiated crosslinked, heat-shrinkable, modified polyolefin tubing
Specifications +
Additional Information
| Colour | Green |
|---|---|
| Unit of Measure | Each |
| Material | Modified Polyolefin |
| Approx Supplied Layflat | 11 |
| Inner Dimension mm | 6.4mm |
| Length | 1.22m |
| Operating Temperature | -25°C - +125°C |
| Outer Dimension | No |
| Recovered Inner Dimension mm | Not Applicable |
| Shrink Ratio | 2:1 |
| Width | No |
| Shrink Temperature | 70 - 125°C |
| Supplied Inner Dimension mm | 6.5+ - 0.4 |
| Supplied Outer Dimension mm | Not Applicable |
| Voltage Rating | 600V |
